THE SMALLEST WEATHER-RESISTANT SLR CAMERA, 50-200mm lens
Weather resistant body
New compact lens with WR construction
Built-in Wifi and NFC modules with dedicated button for instantaneous communication
with smartphones or tablet
Dedicated Application for remote control and sharing on social networks
Selfie assistance
20 MP stabilised CMOS sensor with AA fi lter-less
Sensitivity up to 51 200 ISO
MRP RS. 1,62,000.00
Full HD recording with 30 fps frame rate, H.264 codec
Model Description
| Type | TTL autofocus, auto-exposure SLR digital-still camera with built-in retractable P-TTL flash |
|---|---|
| Lens Mount | PENTAX KAF2 bayonet mount (AF coupler, lens information contacts, K-mount with power contacts) |
| Compatible Lens | KAF3, KAF2 (power zoom not compatible), KAF, KA mount lens |
Image Capture Unit
| Image Sensor | Primary color filter, CMOS. Size: 23.5 x 15.6 (mm) |
|---|---|
| Effective Pixels | Approx. 20.12 megapixels |
| Total Pixels | Approx. 20.42 megapixels |
| Dust Removal | SP coating and CMOS sensor operations |
| Sensitivity (Standard output) | ISO AUTO/100 to 51200 (EV steps can be set to 1EV, 1/2EV, or 1/3EV) |
| Image Stabilizer | Sensor shift Shake Reduction |
| AA Filter Simulator | Moiré reduction using SR unit. OFF/Type1/Type2/Bracket |
File Formats
| File Format | AW (PEF/DNG), JPEG (Exif 2.3), DCF2.0 compliant |
|---|---|
| Recorded Pixels | JPEG: L (20M: 5472x3648), M (12M: 4224x2816), S(6M: 3072x2048), XS (2M: 1920x1280) RAW: L (20M: 5472x3648) |
| Quality Level | RAW (12bit): PEF, DNG JPEG: ★★★ (Best), ★★ (Better), ★ (Good), RAW and JPEG simultaneously recordable |
| Color Space | sRGB, AdobeRGB |
| Storage Medium | SD, SDHC and SDXC Memory Card (Conforms to USH-1 standards), Eye-Fi card, FLU card. |
| Storage Folder | Folder name: Date (100_1018,101_1019...) or User assigned folder name (Default "PENTX") |
| Recording File | File name: "IMGP****" or User assingned file name File name numbering: Sequential, Reset |
Viewfinder
| Type | Pentaprism Finder |
|---|---|
| Coverage (FOV) | Approx. 100% |
| Magnification | Approx. 0.95x (50mmF1.4 at infinity) |
| Eye-Relief Length | Approx. 20.5mm (from the view window), Approx. 22.3mm (from the center of lens) |
| Diopter Adjustment | Approx. -2.5m to + 1.5m-1 |
| Focusing Screen | Interchangeable Natural-Bright-Matte III focusing screen |
Live View
| Type | TTL method using CMOS image sensor |
|---|---|
| Focusing Mechanism | Contrast detection (Face Detection, Face Detection Assist, Tracking, Multiple AF points, Select, Spot) Focus peaking: ON/OFF |
| Display | Field of View approx. 100%, Magnified view (2x, 4x, 8x, 10x), Grid display (4x4 Grid, Golden Section, Scale display), Histogram, Bright area warning |
LCD monitor
| Type | Vari-angle TFT color LCD monitor featuring an air-gapless structure, tempered-glass front panel |
|---|---|
| Size | 3.0 inches (3:2) |
| Dots | Approx. 921K dots |
| Adjustment | Brightness, Saturation and Colors adjustable |
White Balance
| Type | TTL method using CMOS image sensor |
|---|---|
| White Balance | AUTO WB, Multi Auto WB, Daylight, Shade, Cloudy, Fluorescent Light (D:Daylight Color, N:Daylight White, W:Cool White, L:Warm White), Tungsten Light, Flash, CTE, Manual WB, Color Temperature Configuration, Copying the white balance setting of a captured image |
| Fine Adjustment | Adjustable ±7 steps on A-B axis or G-M axis |
Autofocus System
| Type | TTL: phase-matching autofocus |
|---|---|
| Focus Sensor | SAFOX X, 11 point (9 cross type focus points in the center) |
| Brightness Range | EV-3 to 18 (ISO 100 / at normal temperature) |
| AF Mode | Single AF (AF.S), Continuous AF (AF.C), Auto select AF (AF.A) |
| AF Point Selection | Auto:11 points, Auto:5 points, Select, Expanded Area Select, Spot |
| AF Assist Light | Dedicated LED AF assist light |
Metering
| Type | TTL open aperture, 77 segmented metering, center-weighted and spot metering |
|---|---|
| Metering Range | EV0 to 22 (ISO100 at 50mm F1.4) |
| Exposure Mode | Auto Picture mode (Standard, Portrait, Landscape, Macro, Moving Object, Night Scene Portrait, Sunset, Blue Sky, Forest), Scene Mode (Portrait, Landscape, Macro, Moving Object, Night Scene Portrait, Sunset, Blue Sky, Forest, Night Scene, Night Scene HDR*, Night Snap, Food, Pet, Kids, Surf & Snow, Backlight Silhouette, Candlelight, Stage Lighting, Museum) Advanced HDR* (Exposure bracket value selectable from ±1, ±2 or ±3EV ) Program, Sensitivity Priority, Shutter Priority, Aperture Priority, Shutter & Aperture Priority, Manual, Bulb * JPEG only |
| EV Compensation | ±5EV (1/2EV steps or 1/3EV steps can be selected) |
| AE Lock | Can be assigned to the AF/AE-L button |
Shutter
| Type | Electronically controlled vertical-run focal plane shutter |
|---|---|
| Shutter Speed | Auto:1/6000 to 30 sec., Manual: 1/6000 to 30 sec. (1/3EV steps or 1/2EV steps), Bulb |
Drive modes
| Mode Selection | [Still Image] Single frame, Continuous (H, L), Self-timer (12s., 2s., Continuous), Remote Control (0s., 3s., Continuous), Bracketing, Multi-exposure (Possible to use with Continuous, Self-timer or Remote Control), Interval Shooting, Interval Composite [Movie] Remote Control, Interval Movie Record, Star Stream * Bracketing, Interval Shooting, Interval Composite, Interval Movie Record and Star Stream are possible to use with Self-timer or Remote Control. |
|---|---|
| Continuous Shooting | Max. approx. 5.5 fps, JPEG (L: ★★★ at Continuous H): up to approx. 30 frames, RAW: up to approx. 9 frames Max. approx. 3.0 fps, JPEG (L: ★★★ at Continuous L): up to approx. 100 frames, RAW: up to approx. 14 frames *ISO100 |
| Multi-Exposure | Composite Mode: Additive/ Average/ Bright Number of Shots: 2 to 2000 images |
| Interval Shooting | [Interval Shooting] Interval: 2s. to 24h./ Standby Interval: Min.ï½¥1s. to 24h., Number of shots: 2 to 2000 images, Start Interval: Now/Set Time [Interval Composite] Interval: 2s. to 24h./ Standby Interval: Min.ï½¥1s. to 24h., Number of shots: 2 to 2000 images, Start Interval: Now/Set Time, Composite Mode: Additive/Average/Bright, Save Process: On/Off [Interval Movie] Recorded Pixels: 4K/FullHD/HD, Interval:2s. to 24h./ Standby Interval: Minï½¥1s. to 24h., Number of shots: 8 to 2000 images (8 to 500 images at 4K), Start Interval: Now/Set Time [Star Stream] Recorded Pixels: 4K/FullHD/HD, Interval:2s. to 24h./ Standby Interval: Minï½¥1s. to 24h., Number of shots: 8 to 2000 images (8 to 500 images at 4K), Start Interval: Now/Set Time, Fade-out: Off/Low/Medium/High |
Flash
| Built-in Flash | Built-in retractable P-TTL flash, GN: approx. 12 (ISO100/m), Angle of view of 28mm lens (35mm format equivalent) |
|---|---|
| Flash Mode | Auto Flash Discharge, Auto Flash + Red-eye Reduction (Auto Picture, Scene) Flash On, Flash On+ Red-eye Reduction, Slow-speed Sync, Trailing Curtain Sync, Manual Flash Discharge (Full-1/128) |
| Sync Speed | 1/180 sec. |
| Flash Exposure Compensation | '-2.0 to + 1.0EV |
| External Flash | P-TTL, Leading Curtain Sync, Trailing Curtain Sync, Contrast-control-sync, High-speed sync, wireless sync (available with 2 dedicated external flash) |
Capture Setting
| Custom Image | Bright, Natural, Portrait, Landscape, Vibrant, Radiant, Muted, Bleach Bypass, Reversal Film, Monochrome, Cross Processing |
|---|---|
| Cross Processing | Random, Preset 1-3, Favorite 1-3 |
| Digital Filter | Extract Color, Replace Color, Toy Camera, Retro, High Contrast, Shading, Invert Color, Unicolor Bold, Bold Monochrome |
| HDR Capture | Auto, Type1, Type2, Type3, Bracket Value adjustable, Auto Align: On/Off |
| Clarity Enhancement | On/Off |
| Lens Correction | Distortion Correction, Peripheral Illumin. Correction., Lateral Chromatic Aberration Adj., Diffraction Correction |
| D-Range Settings | Highlight Correction, Shadow Correction |
| Noise Reduction | Slow Shutter Speed NR, High-ISO NR |
| Electronic Level | Displayed in viewfinder : Horizontal direction only, Displayed on LCD monitor: Horizontal and vertical direction |
| Horizon Correction | SR On: correction up to 1 degrees, SR Off: correction up to 1.5 degrees |
Movie
| File Format | MPEG-4 AVC/H.264 (MOV) |
|---|---|
| Recorded Pixels Frame rate |
