World-Leading SmartEco Technology
Blu-ray Full HD 3D Supported
Short-Throw Projection
0.5W in Standby Mode
LAN Control with Crestron and PJ-Link
**
Projection System: DLP
Resolution:XGA(1024X768)
Brightness (ANSI Lumens): 3000
Contrast Ratio: 13000:1
Display Color: 1.07 Billion Colors
Lens: F=2.6 f=6.9mm
Aspect Ratio: Native 4:3 (5 aspect ratio selectable)
Throw Ratio: 0.61 (78″@0.96m)
Image Size (Diagonal): 60″-300″
Zoom Ratio: Fixed
Lamp Type: 190W
Lamp Mode (Normal/Economic)*: 4500/6000/6500/10000 hours
Keystone Adjustment: 1D, Vertical ± 30 degrees
Projection Offset**: 130% ± 5%
Resolution Support: VGA(640 x 480) to WUXGA_RB(1920X1200) *RB=Reduced blanking
Horizontal Frequency: 15-102KHz
Vertical Scan Rate: 23-120Hz
HDTV Compatibility: 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
Video Compatibility: NTSC, PAL, SECAM
Weight (Without Packing / With Packing): 2.6kg(5.73bs)
Dimensions (W x H x D mm): 287.3 x 114.4 x 232.6
Interface: Computer in (D-sub 15pin) x 2(Share with component)
Monitor out (D-sub 15pin) x 1
Composite Video in (RCA) x 1
S-Video in (Mini DIN 4pin) x 1
HDMI x 1
Audio in (Mini Jack) x 2
Audio out (Mini Jack) x 1
Audio L/R in (RCA) x 1
Speaker x 1 (10W)
USB (Type Mini B) x1 (Download & page/down)
RS232 (DB-9pin) x 1
LAN (RJ45) x 1
Power Consumption: 270W(typical), Network standby <6W, Standby <0.5W
Power Management Function
Automatic power off after 20 minutes without a display source.
Audible Noise (Normal/Economic Mode)
32/28 dBA
3D Support and Compatibility
Frame Sequential: Up to 480i
Frame Packing: Up to 24Hz 1080p
Side by Side: Up to 60Hz 1080i
Top Bottom: Up to 24Hz 1080p
Picture Modes
Dynamic/Presentation/sRGB/Cinema/(3D)/User 1/User 2
Accessories (Standard)
Lens Cover
Remote Control w/ Battery
Power Cord (by region)
User Manual CD
Quick Start Guide
Warranty Card (by region)
VGA(D-sub 15pin) Cable
Accessories (Optional)
PointWrite
Spare Lamp Kit
Ceilling Mount: Wall Mount
Carry bag
Power Supply:
AC100 to 240 V, 50 to 60 Hz
